New
Model: M551-2
$1,659.00 USD
Create pixel-perfect imagery with the high-end panel quality of the fully professional NEC M Series large format displays. By focusing on customer needs while also offering professional reliability, the M series displays give customers a digital signage display lineup without all the costs. The M series can support both landscape and portrait orientations while also allowing the modularity possibilities to customize their needs dependent on their application and use. The new series contain a full metal mechanical chassis, allowing for a more robust design necessary for commercial applications while maintaining the attractive aesthetics that allow the focus of onlookers to be on what matters – the message. Simple and targeted connectivity options allow customers to have the up-to-date options that they need while not having to overpay for excess and unused interfaces. The NEC M series boasts 500 cd/m² brightness which is ideal for a majority of digital signage applications in corporate, higher education, restaurant, retail and grocery store environments when the focus should be on the message, not the budget. Share your message, your way.

  • 4K UHD native resolution allows for crystal clear imagery and messaging that become more vivid and lifelike than ever before!
  • Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
  • Accepts Intel® Smart Display Module Small or Large allowing for sleek all-in-one intelligence and interoperability in a small form factor setting by accepting Intel processor-based products and other peripherals directly into the displays*
  • Raspberry Pi Compute Module 4 allows for future proof expansion directly into the display
  • Bidirectional and Full External Control allows for easy integration into control systems via LAN or RS232C
  • 500 cd/m2 brightness and HDR compatibilty will capture the attention of audience in almost any situation
  • Integrated Media Player allows for audio, video or image playback via USB
  • 24/7 commercial runtimes with built-in real-time clock and full scheduler capabilities
  • Failover Capabilities with full Input Detect functionality allow peace of mind as the display will automatically switch to a secondary or tertiary source if the primary source fails
  • Energy Star 8.0 Certified Product
  • Full 3 year commercial warranty to allow for peace of mind and protection of your investment
  • NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations

    *There may be limitations dependent on the SDM PC device that’s being used. Please reach out to your Sharp NEC representative for more information.



Legal Disclaimer To California Residents
WARNING: This product can expose you to chemicals including Styrene and Formaldehyde (gas), which are known to the State of California to cause cancer, and Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov


Display

Panel Technology VA Viewable Image Size 55 "
Aspect Ratio 16:9 Screen Resolution 3840x2160
Supported Resolutions DIsplayPort: V1.2 (HDCP 1.3/2.2)VGA60, SVGA60, XGA60, SXGA60, UXGA60, WUXGA60, 1920 x 1080 (60Hz), 1080p, 1080i, 720p@50 Hz/60 Hz, 576p@50 Hz, 480p@60 Hz, 3840x2160 (24 Hz/25 Hz/30 Hz/50 Hz/60 Hz), 4096x2160 (24 Hz/25 Hz/30 Hz/50 Hz/60 Hz)HDMI (HDCP 1.4/2.2)VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60, WUXGA60, 1920x1080 (60 Hz), 1080p, 1080i, 720p@50 Hz/60 Hz, 576p@50 Hz, 480p@60 Hz, 576i@50 Hz, 480i@60 Hz, 3840x2160 (24 Hz/25 Hz/30 Hz/50 Hz (MODE2)/60 Hz (MODE2)),4096x2160 (24 Hz/25 Hz/30 Hz/50 Hz (MODE2)/60 Hz (MODE2)) Pixel Pitch 0.32 mm
Pixels Per Inch 81 @ native resolution Backlight Type LED Direct-lit
Brightness (typical) 500 cd/m2 Contrast Ratio (typical) ≥8,000:1 (Out of the box conditions, local dimming ON)
Viewing Angle (typical) 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10 Response Time (Gray to Gray) 8 ms
Refresh Rate 60Hz Active Screen Area 47.2 x 26.8 in. / 1209.6 x 680.4mm
Orientation Landscape/Portrait Dimming Capability Local Dimming Capable
Displayable Colors More than 1.07 billion (8-bit+FRC) Color Temperature (Max) (°K) 10000K
Color Temperature (Min) (°K) 2600K Gamma (Typical) Native, 2.2, 2.4, S-Gamma, DICOM, Programmable1, Programmable2, Programmable3

Synchronization Range

Horizontal (Analog/Digital) Digital: 26.0 - 135.0kHz Vertical Digital: 23.0 - 86.0Hz

Input Signal

Video Digital TMDS / DisplayPort

Signal Compatibility/Connectivity

PC Signal Compatibility Yes Macintosh Signal Compatibility Yes
Video Digital TMDS / DisplayPort External Control LAN and RS232 In - Full external control capabilities
Input Terminals
Digital:
HDMI (2.0 x 2 with HDCP), DisplayPort (1.2 with HDCP)
Audio:
3.5 Mini-Jack x2, DisplayPort Audio, HDMI Audio x3
External Control:
RS-232C, LAN (100Mb), 3.5mm Mini-Jack (IR Remote)
Data:
USB 2.0 (Media Player)
Output Terminals
Audio:
3.5mm Mini-Jack

Power Consumption (typical)

On 120W ECO Mode Standby <0.5W
Network Standby 0.5W Power Consumption (max) 120W (Max Brightness), 265W (Brightness Max, SDM Max, Volume Max)
Power Savings Mode 2 W

Physical Specifications

Bezel Width (Left/Right, Top/Bottom) 0.55 in./0.55 in., 0.55 in./0.55 in. : 13.9 mm/13.9 mm, 13.9 mm/13.9 mm Dimensions (WxHxD)
Without stand:
48.9 x 28.1 x 2.5 in. / 1241.8 x 712.6 x 62.6 mm
Shipping:
56.3 x 36.2 x 9.8 in. / 1430.0 x 920.0 x 250.0mm
Weight
Net Weight (without stand):
41.4 lbs. / 18.8 kg.
Shipping:
65.0 lbs. / 29.5kg
VESA Hole Configuration 400 x 400mm (M6 x 4-hole)

Environmental Conditions

Operating Humidity 20 - 80% Operating Altitude 9843 ft. / 3000m
Storage Temperature -4-140°F / -20-60°C Storage Humidity 10-80%
Storage Altitude 40,000 ft. / 12,192m

Environmental Compliance

ENERGYSTAR Energy Star 8.0

Limited Warranty (parts & labor)

3 years Advanced Exchange

Additional Features

  • AMX Support
  • Automated Email Alert Function
  • ARC Support through HDMI
  • Crestron Roomview Support (FW Update)
  • Display Browser Control
  • Display Wall Calibrator Compatible
  • HDR Support (PQ, HLG, HDR10)
  • Key Guide
  • NaViSet Administrator 2 Compatible
  • OSD Rotation for Portrait Orientation
  • Accepts Intel(R) SDM-S or SDM-L
  • PJ Link Support
  • Power USB Port (5V/2A)
  • Raspberry Pi Compute Module 4 Compatible
  • Removeable Logo Ornament
  • Real Time Clock
  • Local Dimming
  • TileMatrix
  • SNMP
  • Consumer Electronics Control (CEC)
  • Integrated USB Media Player
  • Integrated Temperature sensor
  • Full Input Detect Functionality
  • Programmable Gamma
  • Energy Star 8.0
  • Scheduler Function
  • Off Timer
  • Vacation Switch


Accessories

Included
  • 3m Power cord
  • 2.0m HDMI cable
  • Wireless remote control
  • Batteries
Optional
  • Wall Mount (WMK-3298T)
  • IR/Human Sensor Accessory (KT-RC3)
  • Table Top Stand (ST-43M)
  • SDM Tuner (DS1-TM01)
  • Table Top Stand (ST-401)

Cooling Method

Integrated Temperature Sensor and Cooling Fan for SDM

Accepts Intel® Smart Display Modules Large or Small
Accepts Intel® Smart Display Modules Large or Small through clever mechanical and electrical design allowing for sleek all-in-one intelligence and interoperability in a small form factor setting.
Human Sensor (Large Format Displays)
Upon sending movement, allows for automatic adjustment to certain settings and features in the display which can lead to targeted messaging for dual-purpose display in digital signage or presentation applications.
4K Resolution
Provides the ultimate in screen clarity.
Built-In Speakers
Enhance the visual experience with superior sound
Round-The-Clock Scheduler
Allows for advanced scheduling of monitor powering up/down, increasing panel lifetime, reducing power consumption and saving the time and expense of finding and purchasing a third-party scheduling solution.
Integrated MultiMedia Player
Allows the ability to play video, audio or image files directly off USB.
Raspberry Pi Compute Module Compatible
The Raspberry Pi Compute Module 4 NEC Edition is the smartest combination of computing power with professional yet cost-effective Signage displays for use in retail environments, passenger information, quick service menu boards and so many more applications.

Large Screen Display Wall Mounts/Stands

Optional Tabletop Stand

Smart Display Modules

Intel® Smart Display Module (SDM)

  • 3m Power cord
  • 2.0m HDMI cable
  • Wireless remote control
  • Batteries
  • Setup Guide
